Sales Unit1 piece(s)
-
User InterfacePhysical/remote
-
Number of faders17
-
DSP Input channels32
-
Mic Preamp16
-
Physical outputs14
-
Digital stagebox connectionAES50
-
HotspotNo
-
Multitrack RecordYes
-
integratated Player/Rec via USB/SDstereo
-
19″ RackmountNo
-
Max.number of input channels32
-
Microphone Inputs16
-
Analog Line Inputs32
-
Analog Line Outputs16
-
DSP Output Channels24
-
Analog in/ out with plug-in card expandableYes
-
Busses16
-
Digital InputsNone
-
Mono-Line Input6
-
Digital OutputsAES
-
Stereo-Line Input0
-
Digital in-/ outputs expandableYes
-
MotorfaderYes
-
EthernetEthernet
-
Computer interfaceUSB, Ethernet
-
MIDI-interfaceYes
-
Special FeaturesCompatible with BEHRINGER P-16 Personal Monitoring System, 32 in / 32 out FW Interface
-
Soundcard interfaceUSB-B
-
Recorder FormatWAV
-
Scribble StripsYes
-
RTAYes
-
FX Processor8
-
31 Band EQ8
-
Delay InputYes
-
Delay OutputYes
-
Matrix6
-
DCA/VCA Groups8
-
Midi ConnectorMidi-Din
-
Sample rate48 kHz
-
Monitor AppsYes
-
Separate Personal Monitor systemOptional
-
Expansion Card slots1
-
Digital ADATOptional
-
Digital SPDIFNo
-
Digital AES3/ASESEBYes
-
Digital MADIOptional
-
Digital DanteOptional
-
110V capableYes
-
CaseIncluded
-
Height215 mm
-
Width625 mm
-
Depth510 mm
-
Weight15,4 kg
A powerhouse mixing console of compact size
The Behringer X32 instantly became a milestone among mid-priced digital mixing consoles when it first appeared, and it has lost none of its appeal since then. Its clear workflow and interactive user interface together with the sheer wealth of features on offer made a lasting impact on the market and delighted countless users along the way. The space-saving “Compact” version of the X32 has eight faders fewer – and is thus 27cm narrower – than its bigger brother, without any sacrifices in terms of functionality. The X32 allows 16 mic or line inputs and six AUX signals to be easily mixed in an intuitive fashion – whether live or in the studio. The X32 Compact’s internal plug-ins and modern network connectivity come into their own when mixing bands with extensive lineups, proving that it has the performance to match its looks. As a front-of-house mixing desk, it is easy to use and can be operated in conjunction with AES50 and Ultranet-capable devices such as stageboxes, monitor mixers, and speakers.
A digital genie
The Behringer X32 Compact is a ground-breaking digital mixer that comes at a budget-friendly price and has fulfilled a wide range of needs for many years. Motorised faders with 100mm travel? Check! XLR outputs? The X32 has eight of them. Backlit control elements? Done! And the digital mixer also allows engineers to record using an external USB drive, control the mix remotely from an iPad, and view their parameters in detail on its 7” TFT colour display. What is more, each channel strip features a mini-LCD screen with backlighting, ensuring a clear overview at all times, even in low light. The X32 Compact can even be expanded to an impressive 96 inputs using an AES50 bus and additional stageboxes. However, it is also ideal for use as a studio mixing desk thanks to its 32-in/32-out USB audio interface with DAW connectivity.
